BASSBOSS DiaMon-RP-EW Compact Remote Powered Point Source Loudspeaker
The BASSBOSS DiaMon-RP-EW delivers remarkably powerful and articulate sound from an exceptionally compact enclosure by placing a 3 inch compression driver through the center of its 12 inch neodymium woofer. This true coaxial architecture creates a coherent point source with consistent 80° conical coverage, clear off axis response, and strong feedback rejection. With 123 dB sustained output, 126 dB peak SPL, and an elegant enamel white finish, it provides discreet professional performance for premium venues, architectural installations, distributed systems, monitoring, and compact mains paired with BASSBOSS subwoofers. This passive bi amplified loudspeaker requires a BASSBOSS preprogrammed amplifier with embedded signature DSP, sold separately.
Why Choose the BASSBOSS DiaMon-RP-EW?
The shared coaxial architecture allows the high frequencies to pass through the center of the woofer rather than requiring a separate horn beside it. This reduces the cabinet size while maintaining phase coherent coverage, intelligible sound, and consistent tonal response throughout the listening area.
A 12 inch neodymium woofer handles the low and midrange frequencies, while the coaxially mounted compression driver provides clear high frequency reproduction. Its sealed birch plywood enclosure, broad placement flexibility, strong feedback rejection, and refined white finish make the DiaMon-RP-EW an excellent choice for professionals looking to buy a compact installation loudspeaker with output that exceeds expectations for its size.
Key Features
• Compact two way passive bi amplified point source architecture
• True coaxial design for phase coherent sound and clear imaging
• Exceptional output to size ratio for discreet professional installations
• 123 dB sustained output and 126 dB peak SPL
• 80Hz to 18kHz frequency response
• Consistent 80° conical dispersion with clear off axis response
• Strong feedback rejection for monitoring and installed applications
• 12 inch neodymium woofer with 3 inch copper voice coil
• 3 inch diaphragm compression driver with 1.4 inch exit
• 1200W total bi amplified power requirement with 900W LF and 300W HF channels
• Requires a BASSBOSS preprogrammed amplifier with embedded signature DSP, sold separately
• Dual speakON NL4 input and thru connections
• Sealed birch plywood enclosure with 35mm pole socket
• Premium enamel white finish for refined architectural spaces
Technical Specifications
| Category | Specification | Details |
|---|---|---|
| System | Configuration | 2 Way Passive Bi Amplified Single 12" Coaxial Point Source Loudspeaker |
| Enclosure Type | Sealed, Direct Radiating Mid High | |
| Frequency Response | 80Hz to 18kHz (±3 dB) | |
| Maximum Sustained Output | 123 dB SPL | |
| Maximum Peak SPL | 126 dB SPL | |
| Dispersion | 80° Conical | |
| Nominal Impedance | 8 Ohms | |
| Amplification | Required Amplification | 1200W Total Bi Amplified |
| LF Amplification | 900W | |
| HF Amplification | 300W | |
| Amplifier and DSP Requirement | External BASSBOSS Preprogrammed Amplifier with Embedded Signature DSP | |
| Transducers | LF Transducer | 1 × 12" (300mm) Neodymium Woofer with 3" (76mm) Copper Voice Coil |
| HF Transducer | 1 × 3" (76mm) Diaphragm Compression Driver with 1.4" (35mm) Exit | |
| Waveguide | 80° Conical Horn Profile Through the Woofer Pole Piece | |
| Connectivity | Audio Connections | 2 × speakON NL4 Input and Thru |
| Construction | Cabinet | Birch Plywood |
| Finish | Enamel White | |
| Grille | Perforated, Powder Coated Steel | |
| Mounting | Pole Socket | 35mm Bottom Pole Socket |
| Environment | Intended Environment | Indoor Professional Installations |
| Physical | Dimensions | 14" × 14" × 11.5" (356 × 356 × 292mm) |
| Net Weight | 38 LB (17.2 KG) | |
| Shipping Weight | 51 LB (23 KG) |
Ideal Applications for the BASSBOSS DiaMon-RP-EW
Designed for nightclubs, lounges, bars, restaurants, premium retail spaces, houses of worship, multipurpose venues, studios, fitness facilities, compact mains paired with BASSBOSS subwoofers, stage monitoring, satellite systems, distributed fills, and architectural installations requiring a refined white finish.
Purchase Information
Items Included
The package includes one BASSBOSS DiaMon-RP-EW Passive 12 Inch 2 Way Coaxial Loudspeaker in Enamel White. Required BASSBOSS amplification and signature DSP are sold separately.
Limited Manufacturer Warranty
The limited manufacturer warranty provides 2 years of coverage for the transducer and 6 years of coverage for the cabinet.
Product Information
Brand: BASSBOSS
Model: DIAMON-RP-EW
UPC: 855591006548
