BASSBOSS DiaMon-RPW-PB Passive Loudspeaker

BASSBOSS DiaMon-RPW-PB Weatherized Coaxial Point Source Loudspeaker

The BASSBOSS DiaMon-RPW-PB delivers powerful, coherent point source sound from a compact weatherized enclosure designed for indoor and weather exposed professional installations. Its true coaxial architecture places a 3 inch diaphragm compression driver through the center of a 12 inch neodymium woofer, producing consistent 80° conical coverage with clear off axis response and strong feedback rejection. With 1200W of passive bi amplified power handling, response from 80Hz to 18kHz, 123 dB continuous output, and 126 dB peak SPL, it provides flexible performance as a main, monitor, fill, or satellite loudspeaker.

Why Choose the BASSBOSS DiaMon-RPW-PB?

The coaxial driver configuration aligns the low and high frequency sources at a single point, supporting precise imaging and consistent tonal response throughout the coverage area. This architecture also reduces the cabinet space normally required for a separate high frequency horn, delivering substantial professional output from an exceptionally compact enclosure.

Water resistant treatments protect the enclosure and drivers for weather exposed applications, while the sealed birch plywood cabinet, textured black finish, pole socket, and dual speakON connections support versatile professional deployment. The DiaMon-RPW-PB is an excellent choice for professionals looking to buy a compact weatherized loudspeaker with coherent coverage and seamless BASSBOSS system integration. A BASSBOSS preprogrammed amplifier with Signature DSP is required and sold separately.

Key Features

• Compact two way passive bi amplified coaxial point source architecture
• Weatherized enclosure and driver treatment for exposed applications
• True coaxial design for coherent sound and clear imaging
• 123 dB continuous output and 126 dB peak SPL
• 80Hz to 18kHz frequency response
• Consistent 80° conical coverage with clear off axis response
• 12 inch neodymium woofer with 3 inch voice coil
• 3 inch diaphragm compression driver with 1.4 inch throat
• 1200W total bi amplified power requirement
• 900W LF and 300W HF power allocation
• 8 Ohm nominal impedance
• Requires a BASSBOSS preprogrammed amplifier with Signature DSP
• Dual speakON NL4 input and thru connections
• Sealed birch plywood cabinet with textured black finish
• Integrated 35mm pole socket

Technical Specifications

Ideal Applications for the BASSBOSS DiaMon-RPW-PB

Designed for indoor and weather exposed venue installations, bars, nightclubs, restaurants, retail spaces, houses of worship, fitness clubs, studios, main systems, stage monitoring, distributed fills, satellite applications, and subwoofer supported portable systems.

Purchase Information

Items Included

The package includes one BASSBOSS DiaMon-RPW-PB Weatherized 12 Inch Passive Coaxial Loudspeaker in Black.
The required BASSBOSS preprogrammed amplifier with Signature DSP is sold separately.

Limited Manufacturer Warranty

The limited manufacturer warranty provides 2 years of coverage for the transducer and 6 years of coverage for the cabinet.

Product Information

Brand: BASSBOSS
Model: DIAMON-RPW-PB
UPC: 855591006555
