BASSBOSS KRAKEN-MK3 Flagship Quad 21 Inch Powered Subwoofer
The BASSBOSS KRAKEN-MK3 concentrates four 21 inch neodymium woofers and 10,000W of Class D amplification into a force canceling enclosure built for arena scale low frequency performance. Its sixth order vented short horn hybrid design delivers powerful 27Hz extension, fast transients, impactful upper bass, 145 dB sustained output, and 148 dB peak SPL. Engineered to maximize bass performance per footprint, this flagship subwoofer provides the physical impact and sustained headroom required for stadiums, arena mainstages, headline festival systems, major touring productions, and large club installations.
Why Choose the BASSBOSS KRAKEN-MK3?
Four discrete 2500W amplifier channels power the four 21 inch neodymium woofers independently, providing substantial headroom while distributing the electrical and thermal workload across the system. The dual opposed, force canceling architecture controls cabinet vibration while preserving the fast transient response and upper bass impact required for large scale professional sound.
Integrated 96kHz DSP manages filtering, phase alignment, equalization, cardioid processing, and multi stage limiting. ControlBASS networking, Milan AVB connectivity, universal voltage compatibility, weather resistant construction, and interlocking stacking hardware make the KRAKEN-MK3 a commanding choice for professionals looking to buy a flagship subwoofer with extraordinary output and centralized system control.
Key Features
• Quad 21 inch self powered sixth order vented short horn hybrid architecture
• Dual opposed, force canceling cabinet design
• 10,000W Class D amplification across four discrete 2500W channels
• 145 dB sustained output and 148 dB peak SPL
• 27Hz to 100Hz frequency response
• Four 21 inch neodymium woofers with 4.5 inch voice coils
• Fast transient response and impactful upper bass reproduction
• Cardioid operation using multiple cabinets
• 96kHz DSP with 8 onboard presets
• Storage for up to 100 presets through ControlBASS
• High pass, low pass, phase alignment, equalization, cardioid processing, and multi stage limiting
• Milan AVB networking and Ethernet remote control
• Multi stage limiting, thermal, short circuit, and DC offset protection
• Universal 100 to 240V auto sensing power supply
• IP65 rated Neutrik powerCON True1 TOP power input
• Touring grade 18mm Baltic birch enclosure with extensive internal bracing
• Waterproof and impact resistant textured polyurea finish
• Eight steel bar handles and interlocking stacking hardware
Technical Specifications
| Category | Specification | Details |
|---|---|---|
| System | Configuration | Quad 21" Self Powered Sixth Order Vented Short Horn Hybrid Subwoofer |
| Frequency Response | 27Hz to 100Hz (±3 dB) | |
| Maximum Sustained Output | 145 dB SPL at 1m, Half Space | |
| Maximum Peak SPL | 148 dB SPL at 1m, Half Space | |
| Dispersion | 360° × 360°; Cardioid Mode Available with Multiple Cabinets | |
| Amplification | Total Amplification | 10,000W Class D |
| Amplifier Channels | 4 × 2500W Discrete Channels | |
| Processing | DSP | 96kHz Sampling |
| Presets | 8 Push Button Presets with Storage for Up to 100 Presets | |
| Functions | High Pass, Low Pass, Phase Alignment, Equalization, Cardioid Processing, and Multi Stage Limiting | |
| Protection | Multi Stage Limiting, Thermal, Short Circuit, and DC Offset | |
| Cooling | Cooling System | Blower Fans with Automatic Thermal Management |
| Transducers | Woofers | 4 × 21" (540mm) Neodymium Woofers |
| Voice Coils | 4.5" (115mm) Voice Coils | |
| Connectivity | Signal Input | Balanced XLR F |
| Signal Output | Balanced XLR M Direct Pass Through | |
| Network | 2 × EtherCON RJ45 with 2 Port Ethernet Switch and Milan AVB | |
| DSP Control | ControlBASS for macOS and Windows | |
| Power | Power Input | Neutrik powerCON True1 TOP, IP65 |
| Operating Voltage | 100 to 240V AC, 50 to 60Hz, Auto Sensing | |
| Current Draw | 18A at 120V / 9.2A at 240V | |
| Construction | Cabinet | CNC Machined 18mm Baltic Birch Plywood with Dado Joinery and Extensive Bracing |
| Architecture | Dual Opposed, Force Canceling Cabinet | |
| Finish | High Pressure Bonded Textured Polyurea, Waterproof and Impact Resistant | |
| Handling and Stacking | Handles | 8 Steel Bar Handles |
| Sliders and Feet | 8 Interlocking UHMWPE Sliders and Feet | |
| Deployment | Installation | Ground Stack Only |
| Fly Points | None | |
| Physical | Dimensions | 48" × 48" × 36" (1219 × 1219 × 914mm) |
| Height with Feet | 48.5" (1232mm) | |
| Net Weight | 461 LB (209 KG) | |
| Shipping Weight | 616 LB (280 KG) |
Ideal Applications for the BASSBOSS KRAKEN-MK3
Designed for stadium and arena mainstages, large festival headline systems, major touring sound productions, flagship nightclub installations, large outdoor concert systems, electronic and bass music events, and high output cardioid subwoofer arrays requiring maximum low frequency performance per footprint.
Purchase Information
Items Included
The package includes one BASSBOSS KRAKEN-MK3 10,000W Powered Quad 21 Inch Subwoofer and one power cable.
Limited Manufacturer Warranty
The limited manufacturer warranty provides 3 years of coverage for the electronics and 6 years of coverage for the cabinet.
Product Information
Brand: BASSBOSS
Model: KRAKEN-MK3
UPC: 855591006746
