Why Choose the BASSBOSS SUBLIM8-MK3?
Dedicated amplification supplies 2400W to the integrated subwoofer, 800W to the midrange drivers, and 800W to the compression driver. This active three way architecture keeps each frequency section within its optimal operating range, producing deep low frequencies, clear vocals and instruments, and controlled high frequency coverage from one cohesive system.
The modular design separates into three sections for efficient transport and assembles into a refined 106 inch column with discreet sightlines. Integrated 96kHz DSP, ControlBASS management, universal voltage compatibility, IP rated power connections, and a top mounted lighting power outlet make the SUBLIM8-MK3 an excellent choice for professionals looking to buy a complete, visually elegant PA with touring grade performance and flexible system control.
Key Features
• Complete three way self powered full range column system
• Integrated 18 inch neodymium subwoofer with waterproof cone
• 35Hz to 19kHz frequency response from one modular system
• 130 dB sustained output and 133 dB peak SPL
• Wide 120° horizontal and controlled 20° vertical dispersion
• Two 8 inch neodymium midrange drivers with waterproof cones
• 3 inch compression driver with 1.4 inch exit and isophasic wave guide
• 4000W Class D tri amplification with dedicated LF, MF, and HF channels
• 96kHz DSP with 8 onboard presets
• Storage for up to 100 presets through ControlBASS
• Soft clip, thermal, short circuit, and DC offset protection
• Three section modular design for efficient transport and assembly
• Universal 100 to 240V auto sensing power supply
• IP65 rated Neutrik powerCON True 1 TOP power input
• Top mounted lighting power pass through
• Touring grade birch plywood enclosure with bonded textured polyurea finish
Technical Specifications
| Category |
Specification |
Details |
| System |
Configuration |
3 Way Self Powered Full Range Column System |
|
Frequency Response |
35Hz to 19,000Hz (±3 dB) |
|
Maximum Sustained Output |
130 dB SPL, Half Space |
|
Maximum Peak SPL |
133 dB SPL, Half Space |
|
Dispersion |
120° Horizontal × 20° Vertical |
| Amplification |
Total Amplification |
4000W Class D |
|
LF Amplifier |
2400W |
|
MF Amplifier |
800W |
|
HF Amplifier |
800W |
| Processing |
DSP |
96kHz Sampling |
|
Presets |
8 Push Button Presets with Storage for Up to 100 Presets |
|
Protection |
Soft Clip Limiting, Thermal, Short Circuit, and DC Offset |
| Transducers |
LF Transducer |
1 × 18" Neodymium Woofer with 4" Voice Coil and Waterproof Cone |
|
MF Transducers |
2 × 8" Neodymium Woofers with Dual 2" Voice Coils and Waterproof Cones |
|
HF Transducer |
1 × 3" Diaphragm Compression Driver with 1.4" Exit and Isophasic Wave Guide |
| Connectivity |
Signal Input |
Balanced XLR F |
|
Signal Output |
Balanced XLR M Direct Pass Through, Unprocessed |
|
DSP Control |
ControlBASS Software for macOS and Windows |
| Power |
Power Input |
Neutrik powerCON True 1 TOP, IP65 |
|
Power Output |
Neutrik powerCON True 1, 10A/1200W Maximum |
|
Lighting Power |
Top Mounted Power Pass Through |
|
Operating Voltage |
100 to 240V AC, 50 to 60Hz, Auto Sensing |
|
Nominal Current Draw |
5.4A at 120V / 2.5A at 240V |
| Construction |
Enclosure |
CNC Machined 15mm and 18mm Birch Plywood |
|
Finish |
Bonded Textured Polyurea |
| Physical |
Sections |
3 Section Modular System |
|
Assembled Dimensions |
106" × 19.75" × 24" (269.2 × 50.2 × 61cm) |
|
Disassembled Dimensions |
34" × 37" × 25.75" (86.4 × 94 × 65.4cm) |
|
Net Weight |
201 LB (90.7 KG) |
|
Shipping Weight |
258 LB (117 KG) |
Ideal Applications for the BASSBOSS SUBLIM8-MK3
Designed for high end mobile DJ systems, corporate events, premium ballrooms, small to medium venues, lounges, bars, houses of worship, schools, event centers, live performances, private events, hospitality environments, professional AV installations, and applications requiring wide coverage with discreet sightlines.
Purchase Information
Items Included
The package includes one complete BASSBOSS SUBLIM8-MK3 3 Way Self Powered Column System with all three sections, power cables, and a power cord.
Limited Manufacturer Warranty
The manufacturer warranty provides 3 years of coverage for the transducers and electronics and 6 years of coverage for the cabinet.
Product Information
Brand: BASSBOSS
Model: SUBLIM8-MK3
UPC: 850073264003 (Black)
